50MM LC2500KG Ratchet Cap Slide On Single Boss Winch with 9M Strap AS/NZS 4380
Go with the Slide on Single Boss Winch C/W 9m Strap for a strong, resilient, and versatile option when tying down heavy-duty loads for transit. Designed with a high-strength steel alloy pawl pin, a seamless, solid steel mandrel, and a tough steel frame, this slide on winch has the necessary strength to withstand the harsh daily conditions of flatbed operations. To keep your straps in prime condition, the web slots in the mandrel have been smooth ground, effectively reducing strap wear and abrasion.
Included with the Slide on Single Boss Winch C/W 9m Strap is a resilient 9m winch strap, which comes with 2 wearsleeves for additional durabilty, as well as a hook & keeper to firmly grip anchor points and keep heavy cargo secured. This winch offers a lashing capacity of 2500kg and a versatile slide on design, which allows it to be installed anywhere along either side of a flatbed trailer so you can easily and quickly access it.
Welldone tie down strap are manufactured to the highest standards in accordance with EN12195-2, AS/NZS 4380, WSTDA-T-1. All the ratchet straps must be tested by tensile test machine before shipping.
Advantage: Sample available(To check quality), Customized design(logo printing, special fittings), Different packaging(Shrink, Blister, Polybag, Carton), Short lead time, Multiple payment method(T/T, LC, Paypal, Alipay).
Model Number: WDSTW50HK5T9
Winch Type:Single Boss(Double Boss is available)
Attachment:Slide On
Overall Width:320mm
Spool Width:160mm
Frame Height:240mm
Frame Depth:101mm
Lashing Capacity:2500kg
Length of strap:9-12M
Hook: Swan hook
Other sizes manufactured to order.
Webbing available in alternative colours, please ask for details.
-
Cautions:
Never use lashing strap for lifting.
Never use overload.
Do not twist webbing.
Protect the webbing from sharp or abrasive edges.
Periodic inspect the ratchet strap to ensure the tie down or webbing in good condition, or replace it at once.
